Aluminum Wall Cladding Panels

Certifications

 ISO 9001:2015 | SGS certificated | Critical to Quality Inspections

Aluminum Wall Cladding Panel Manufacturing Capabilities

Capability: 1,200,000 square meters/Year
Material: 1100H24 / 1060H24 / 3003H24 / 5005H24
Thickness: 1.0 ~ 5.0mm are all available
Size: 600*600 / 600*1200mm / 1220*2440mm(standard size)/ customized size
Suraface: Roller coating / PVDF coating / Powder coating
Tolerances: Typically, Alumideas can maintain machining thickness tolerance of ±0.2mm and length or width tolerance of ±2mm.

How To Install Aluminum Wall Cladding?

About how to install aluminum wall cladding panels, as a facade panel manufacturer, we will offer fully guideline to our customers, here’s the installation short introduction:

1. Use vertical transportation equipment such as elevators to transport aluminum plates and accessories to each construction node.

2. The whole aluminum plate is connected with the keel through the surrounding aluminum corner codes (brackets) and fixed on the keel.

3. Fixing method: If it is built-in seamless splicing, drill at the corresponding position on the keel, and then riveted with a flat head (countersunk head) aluminum rivet; If it is seam splicing, use steel drill tail screws (also known as flange screws or phoenix screws) to directly drill into the keel through the holes of the aluminum corner code to stabilize the aluminum plate, but pay attention to control the tightness of the drill bit.

4. When trial assembly, pay attention to the installation accuracy, and adjust the aluminum plate before fastening.

5. When installing, the aluminum panles should be installed on the wall according to its serial number.

aluminum panel installation method drawing

Aluminum wall cladding panel installation method drawing

6. The installation of aluminum wall cladding always starts from the front, large area, and corner parts, and is installed from top to bottom.

7. The connection between the aluminum plate and the keel must meet the requirements of the drawings, it must be firm and stable, and bolts must be installed.
